Chuanglixun CLX-MU9202 MPO Polarity Tester for 12/24/48 Core MPO/MTP Fiber Optic Patch Cords with 110V/220V Power and Polarity Analysis

1
MOQ
$1,035-1,186
prezzo
Chuanglixun CLX-MU9202 MPO Polarity Tester for 12/24/48 Core MPO/MTP Fiber Optic Patch Cords with 110V/220V Power and Polarity Analysis
Caratteristiche Galleria Descrizione di prodotto Richieda una citazione
Caratteristiche
Specificazioni
Fonte di energia: CA 100-240 V
Tipo di connettore: MPO
materiale: plastica
Misurare: 240*400*160 (mm)
Peso netto: 40,0 kg
Peso lordo: 5 chilogrammi
Nucleo del cavo: 24/12/32/48 Nucleo
Voltaggio: 110 V/220 V
Tipo applicabile della fibra: 9/125, 50/125, 62,5/125
Temperatura di funzionamento: -5～+40℃
Alimentazione elettrica: 110 V CA/220 V CA 50 HZ
Temperatura di conservazione: -25～+70℃
Sorgente luminosa: Luce rossa visibile
Supporto dell'interfaccia: USB, rs232
Dimensioni della macchina: 240*400*160 (mm)
Evidenziare:

12/24/48 Core MPO Polarity Tester

,

110V/220V MPO/MTP Fiber Optic Tester

,

Polarity Analysis Fiber Optic Polarity Analyzer
Informazioni di base
Luogo di origine: Guangdong, Cina
Marca: Chuanglixun
Numero di modello: CLX-MU9202
Termini di pagamento e spedizione
Descrizione di prodotto
CLX-MU9202 MPO/MTP Fiber Optic Polarity Tester
Professional 12/24/48 Core MPO Polarity Tester for MPO/MTP Fiber Optic Patch Cords with 110V/220V Power Supply
Chuanglixun CLX-MU9202 MPO Polarity Tester for 12/24/48 Core MPO/MTP Fiber Optic Patch Cords with 110V/220V Power and Polarity Analysis 0 Chuanglixun CLX-MU9202 MPO Polarity Tester for 12/24/48 Core MPO/MTP Fiber Optic Patch Cords with 110V/220V Power and Polarity Analysis 1
Product Overview
The MPO/MTP polarity tester is engineered for precise polarity judgment and continuity analysis during MPO/MTP patch cord production. Utilizing visible red light technology, this device efficiently detects line sequence status for both MPO-MPO patch cords and fan-out cables, providing a fast, accurate, and reliable testing solution for production, semi-finished, and finished product quality control.
Key Features
  • Compatible with 12, 16, 24, 32, and 48-core configurations and special core testing requirements
  • Supports SM 9/125, MM 50/125, and MM 62.5/125 fiber core types
  • User-defined polarity setting capability
  • Study mode with error alarm functionality
  • Advanced error polarity analysis
  • Replaceable MPO connector components for maintenance
  • Connectivity options: USB, RS232, and upper monitor application support
Chuanglixun CLX-MU9202 MPO Polarity Tester for 12/24/48 Core MPO/MTP Fiber Optic Patch Cords with 110V/220V Power and Polarity Analysis 2 Chuanglixun CLX-MU9202 MPO Polarity Tester for 12/24/48 Core MPO/MTP Fiber Optic Patch Cords with 110V/220V Power and Polarity Analysis 3
Technical Specifications
Product Name MPO/MTP Polarity Tester
Application FTTH, FTTB, FTTX Networks
Machine Dimensions 240 × 400 × 160 mm
Weight 4.0 kg
Cable Core Compatibility 12/24/32/48 Core
Applicable Fiber Types 9/125, 50/125, 62.5/125
Operating Temperature -5°C to +40°C
Power Supply 110VAC/220VAC 50HZ
Storage Conditions -25°C to +70°C
Get a Free Quotation via Us >>> GO
Company Profile
Chuanglixun CLX-MU9202 MPO Polarity Tester for 12/24/48 Core MPO/MTP Fiber Optic Patch Cords with 110V/220V Power and Polarity Analysis 4 Chuanglixun CLX-MU9202 MPO Polarity Tester for 12/24/48 Core MPO/MTP Fiber Optic Patch Cords with 110V/220V Power and Polarity Analysis 5
Shenzhen Chuanglixun Optoelectronic Equipment Co., Ltd.
Established in 2010, Shenzhen Chuanglixun Optoelectronic Equipment Co., Ltd. is a comprehensive optical communications equipment company integrating research and development, production, after-sales service, and technical support. We deliver high-quality products with excellent after-sales service and provide complimentary technical assistance for fiber optic connector production challenges.
Frequently Asked Questions
Are you a factory or a trader?
We are a factory.
What is your MOQ?
Minimum order quantity is 1 piece.
Do you provide sample services?
Yes, we provide samples.
How will you ship to me?
We ship via DHL or FedEx within 4 to 6 days, with potential extension based on order quantity.
How do we pay?
Advance booking or multiple payment methods including T/T and T/L.
How long is your product warranty?
1-year warranty with free repairs (excluding consumables). After warranty period, accessories provided at cost.
Do you provide customized services?
Yes, we provide customized services according to customer requirements and specifications.
