Name: High Efficiency Anti-Rust Durable 24 Ports FC UPC Fiber Optic Polishing Jig for Precision Connector Polishing
Brand: Shenzhen Chuanglixun Optoelectronic Equipment Co., Ltd.
SKU: FC UPC-24, FC UPC-24
Price: 220.23 USD
Availability: InStock

High Efficiency Anti-Rust Durable 24 Ports FC UPC Fiber Optic Polishing Jig for Precision Connector Polishing

MOQ

$210.23-230.51

prezzo

Caratteristiche Galleria Descrizione di prodotto Richieda una citazione

Caratteristiche

Specificazioni

Tipo: Adattatore e connettori in fibra

Materiale: Acciaio inossidabile temprato s136

Dimensioni: 174 mmx174 mmx5,1 mm

Peso: 1,2 kg

No. di fibra: 24

Diametro della ferrule: 2,5 mm

Capacità: 24 posizioni

Perdita di inserzione: ≤0.20db

Perdita di ritorno: ≥55dB (PC)

Fine-fronte: PC

Tipo di connettore: PC DI FC

Modello: FC-PC-24

Peso netto: 1,5 chilogrammi

Peso lordo: 2,0 CHILOGRAMMI

Macchine adatte: Lucidatrice CLX-02E, lucidatrice Seikoh Giken SFP-550

Evidenziare:

High Efficiency Polishing Fixture

Anti-Rust Fiber Optic Polishing Jig

Durable Fiber Polishing Fixture

Informazioni di base

Luogo di origine: Guangdong, Cina

Marca: chuanglixun

Numero di modello: FC UPC-24, FC UPC-24

Termini di pagamento e spedizione

Galleria

High Efficiency Anti-Rust Durable 24 Ports FC UPC Fiber Optic Polishing Jig for Precision Connector Polishing

Descrizione di prodotto

24 Port FC UPC Fiber Optic Polishing Jig

This fiber polishing fixture/jig offers high stability and excellent surface quality. Constructed with high-quality heat-treated steel (hardened steel S2316) for extended service life. The fixture can be designed for SC, FC, ST, LC connectors and customized to customer requirements.

Key Features:

Designed specifically for FC/PC connectors
Easy jig changing with simple, flexible operation
High efficiency - polishes up to 24, 32, or 36 connectors per cycle with 98-100% first-pass yield
IPC structure with independent compression for each connector
Exceptional performance: PC return loss ≥55dB, insertion loss ≤0.20dB (typical)
Replaceable accessories significantly extend service life

Technical Specifications:

Model	FC-PC-24	FC-PC-32	FC-PC-36
Brand	CLX	CLX	CLX
Connector Type	FC PC	FC PC	FC PC
End-face	PC	PC	PC
Ferrule Diameter	2.5mm	2.5mm	2.5mm
Capacity	24 positions	32 positions	36 positions
Insertion Loss	≤0.20dB	≤0.20dB	≤0.20dB
Return Loss	≥55dB (PC)	≥55dB (PC)	≥55dB (PC)
Application	Polishing assembled FC PC connectors
Material	Stainless Steel
Dimension (LWH)	17417426 mm
Net Weight / Gross Weight	1.5 kgs / 2.0 kgs
Compatible Machines	CLX-02E polishing machine, Seikoh Giken SFP-550 polishing machine, and similar models

Polishing Performance:

1. Polished Connector Ferrule Faces:

High-quality end-face polishing with no white spots or scratches, clearly visible fiber edges.

2. ILRL Test Results:

Connector Type	SM/UPC	SM/APC	MM/UPC
Insertion Loss	≤0.20dB	≤0.20dB	≤0.50dB
Return loss	≥55dB	≥60dB	≥30dB

3. Geometry Test Results:

Parameter	UPC Criterion	APC Criterion
Radius of Curvature	5-25mm	5-12mm
Apex Offset	0-50μm	0-50μm
Fiber Height	-100~+50μm	-100~+50μm
Angle	n/a	8.00+/-0.50°

Manufacturer Information

Shenzhen Chuanglixun Optoelectronic Equipment Co., Ltd.
Established in 2010, we are an optical communications equipment company specializing in R&D, production, after-sales service and technical support. We provide high-quality products along with comprehensive technical solutions for fiber optic connector production challenges.

Frequently Asked Questions

1. Are you a factory or a trader?

We are the manufacturer.

2. What is your MOQ?

Minimum order quantity is 1 piece.

3. Do you provide sample services?

Yes, we provide samples.

4. How will you ship to me?

Standard shipping via DHL or FedEx takes 4-6 days. Larger orders may require additional time.

5. How do we pay?

We accept advance booking or multiple payment methods including T/T and T/L.

6. How long is your product warranty?

1-year warranty covering free repairs (excluding consumables). After warranty, we provide cost-based replacement parts.

7. Do you provide customized services?

Yes, we offer customization based on customer requirements.
